Recyclable High Rise Workshop Steel Structures Fabrication With
Chinese Standard
Characteristics:
Quick to fabricate
Easy to assemble
Long using time over 50 years
Low cost and maintenance
Environment friendly
Recyclable
Lighter weight
Excellent anti-shock and anti-impact ability
Material Specification Dates:
Main component:
1 | Main steel frame | H section steel beam and columns, painted or Hot-dip galvanized |
2 | Secondary frame : | Hot-dip galvanized C/Z purlin, steel bracing, tie bar, knee brace,
edge cover etc. |
3 | Roof panel : | EPS sandwich panel , glass fiber sandwich panel , rock wool
sandwich panel , and PU sandwich panel or Single steel sheet |
4 | Wall panel : | Sandwich Panel or Corrugated Steel Sheet |
5 | Tie Rod: | Circular Steel Tube |
6 | Brace: | Round Bar |
7 | Knee Brace: | Angle Steel |
8 | Roof Gutter: | Color Steel Sheet or galvanized plate sheet |
9 | Rainspout: | PVC Pipe |
10 | Door: | Sliding Sandwich Panel Door or Rolling Metal Door |
11 | Windows: | PVC/Aluminum Alloy Window |
12 | Connecting: | High strength bolts |
13 | Packing: | There are a steel holder to support all steel members |
14 | Drawing: | We can make the design and offer according to your requirement or
your drawing |
Need Quotation:
1. Data for design
Wind speed (KM/H)
Snow load (KG/M2)
Rain load (KG/M2)
Earthquake load if have
Demands for doors and windows
Crane (if have), Crane span, crane lift height, max lift capacity,
max wheel pressure and min wheel pressure.
2. Material quality
Windows and doors quantity, size and location
Roof and wall material, sandwich panel or corrugated single steel
sheet
3. Type
size--width, length, eave height and roof slope
single slope or double slope
single floor, double floor or multi floor
Application:
steel structure warehouse, workshop, hangar, garage, poultry house,
container house, prefabricated home, high-rise building for office,
shopping mall, hospital, dormitory, school, bus station, railway
station, bridge, etc.
If you are going to build such building, please get in touch with
us, and offer us following information.
| BUILDING INFORMATION FORM |
| We will give you professional technical solution if you can fill
this for and contact with us by e-mail, fax or tel which listed at
the bottom of this form. |
| Compay Name: |
| Client | | Tel/Fax: | | E-mail: | |
| Building Basic Information |
| Project: | | Project No.: | |
| Location | | Building Usage | | | Total area | |
Length
(m) | | Width
(m) | | Eave Height
(m) | |
| Roof material | |
| Wall material | |
| Design Load and Meteorological Conditions |
Wind load
(kn/m2) | | Wind speed
(m/sec) | | Snow load
(kn/m2) | |
Rainfall
Capacity | | Earthquake Grade | |
| Please fill out the below information if your building has the
mezzanine |
| Height of Mezzanine(m) | | Usage of mezzanine | |
| Live load on mezzanine(kn/m2) | |
| Please fill out the below information if your building has the
crane |
Capacity
(t) | | Span
(m) | | Quantity | |
| Hoisting height (m) | | Other information about crane | |
| Building sketch | | | | | | | |
| | | | | | | | | |
| | | | | | | | | |
